China’s Bionic Robot Mimics Cheetah-Like Motion with Advanced Material Technology

The innovative design allows the robot to replicate a cheetah’s gait and climb ramps.



Roboticists and computer scientists have long drawn inspiration from nature to develop advanced robotic systems. A recent study published in the Journal of Bionic Engineering introduces a groundbreaking robot built using piezoelectric materials a special class of materials that generate an electric charge when subjected to mechanical stress.



The newly developed H-shaped Bionic Piezoelectric Robot (H-BPR) successfully achieves linear and turning motion using a voltage differential driving method. The prototype, weighing just 38 grams and measuring 150 × 80 × 31 mm³, effectively mimics the running gait of a cheetah while demonstrating superior climbing abilities.



Mimicking Nature with Piezoelectric Motion

The H-BPR consists of four legs connected by three piezoelectric beams. By leveraging the bending vibrations of these beams, the robot replicates the periodic leg movements characteristic of a cheetah’s sprint.



To refine its movement capabilities, researchers analyzed the dynamics and kinematics of the robot, studying the trajectory of its leg movements. They then conducted modal and harmonic response analyses using finite element analysis software to optimize performance.

Performance and Capabilities

According to the study, the robot achieved:

• Maximum velocity: 66.79 mm/s at an excitation voltage of 320V

• Load capacity: 55 grams

• Improved climbing performance with unequal drive legs, providing valuable insights for optimizing leg design in future piezoelectric robots.



Unlike traditional robots that rely on wave propagation in piezoelectric materials for movement, this design simplifies the mechanism, making it easier to manufacture while offering greater control over movement and turning radius through voltage adjustments.

Future Applications: Miniature Sensors and Extreme Environments

The prototype is currently capable of carrying small loads, opening possibilities for integrating miniature sensors or cameras for enhanced functionality.



Looking ahead, researchers plan to refine the design to improve performance in extreme temperatures, harsh environments, and hazardous conditions. This could pave the way for applications in industrial automation, search-and-rescue missions, and environmental monitoring.



With its innovative use of piezoelectric materials and nature-inspired locomotion, the H-BPR represents a significant step forward in bionic robotics, demonstrating how material science can shape the future of robotics.
